MFD
| SPECIFICATION | MFD – 20 |
|---|---|
| Internal Dimension (WxDxH) | 1110 x 480 x 1200 |
| External Dimension (WxDxH) | 1200 x 680 x 2020 |
| Gross Volume (Liters) | 640 |
| Temperature Range (°C) | -18 to -20 |
| Climate Class | 27 °C / 70 % RH |
| Temperature Controller | Digital Control |
| Compressor | Reciprocating : 1 HP Type : Horizontal |
| Defrost System | Heater Defrost |
| Rated Voltage | 1 Phase / 220v – 240v |
| Rate Frequency | 50 Hz |
| Power Input | Fan Condenser : 0.60 A x 2 : 4.12 w x2 Fan Evap : 0.36 A x 2 : 4.12 w x 2 Lighting : 0.07 A : 10.50 w Compressor : 4.16 A : 732.2 w Heater Defrost : 2.0 A : 350 w Heater Drain : 1.06 A : 200 w Heater Door : 1.20 A x2 : 265 w x 2 Compressor : 5.0 A : 900 w |
| Air Flow | Supply : 2.3 m/s Return : 0.5 m/s |
| SPECIFICATION | MFD – 30 |
|---|---|
| Internal Dimension (WxDxH) | 1660 x 480 x 1200 |
| External Dimension (WxDxH) | 1750 x 680 x 2020 |
| Gross Volume (Liters) | 955 |
| Temperature Range (°C) | -18 to -20 |
| Climate Class | 27 °C / 70 % RH |
| Temperature Controller | Digital Control Carel |
| Compressor | Reciprocating : 1 1/2 HP Type : Horizontal |
| Defrost System | Heater Defrost |
| Rated Voltage | 1 Phase / 220v – 240v |
| Rate Frequency | 50 Hz |
| Power Input | Fan Condenser : 0.60 A x 2 : 4.12 w x2 Fan Evap : 0.36 A x 2 : 4.12 w x 2 Lighting : 0.07 A : 10.50 w Heater Defrost : 2.0 A : 350 w Heater Drain : 1.06 A : 200 w Heater Door : 1.20 A x2 : 265 w x3 Compreeser : 4.30 A |
| Air Flow | Supply : 2.3 m/s Return : 0.5 m/s |
